MIL-DTL-27444E
TABLE IV. Requirement verification matrix - Continued
REQUIREMENT
VERIFICATION METHOD
VERIFICATION
3.13 Dimensional
4.5.1 Examination
Examination
tolerances.
of product.
4.5.1 Examination
3.14 Workmanship.
Examination
of product.
4.3 First article testing.
4.3.1 First article test sample. The first article test sample of each type net shall consist of the
following:
a. Two complete nets of each type shall be produced and examined in accordance with
4.5.1. One net shall be used for test specimens and one net shall be retained for
comparison with production nets. The retained net shall be shipped as one of the last
shipments of the contract.
b. Test specimens shall be selected from one of the nets and shall be assembled in the
net. A specimen shall be selected for each type of hardware, except the loop stop,
combined with each type of attached webbing. In places where two or more types of
webbing are attached to one piece of hardware (an example of this is the ring), a
specimen shall be selected for each type of webbing, thread and, sewing pattern used.
In places where two pieces of hardware are assembled together, the test specimen
shall include the assembly. Each test specimen shall be tested in accordance with
4.5.2.
c. In addition to the specimens selected in 4.3.1b, a test specimen shall be selected for
each type of stitch pattern not included in the specimen in 4.3.1b. An example is the
grid area (where webbing is sewn to webbing) stitching. Each test specimen shall be
tested in accordance with 4.5.2.
d. A tensioning mechanism test specimen shall be fabricated and tested in accordance
with the requirements of 4.5.4.1.
4.3.2 Test rejection criteria. Throughout all tests specified herein, the net shall be closely
observed for the following conditions, which shall be cause for rejection:
a. Failure to conform to design or performance requirements specified herein or in the
contractor's technical proposal.
b. Structural failure of any component, including permanent deformation, or evidence of
impending failure (unless otherwise specified).
7
