MIL-DTL-27444E
TABLE I. Minimum breaking strengths.
TYPE
MINIMUM BREAKING STRENGTHS (lbs)
VII
5500
VIII
3600
XIII
6500
3.7.1 Webbing colors. The webbing colors shall be in accordance with FED-STD-595 as shown
in TABLE II.
TABLE II. Webbing colors.
NET TYPE
COLOR
COLOR CHIP NUMBER
CLASSIFICATION
TYPE I
Green
14084, 24084 or 34088
TYPE II
Brown
30277
TYPE V
Green
14084, 24084 or 34088
3.8 Hardware. All hardware shall be installed in accordance with the applicable detail drawing.
All hardware shall be securely sewn to the webbing or otherwise attached to the net.
3.9 Stitching. Stitching design and thread shall be selected by the contractor. The contractor
shall meet the requirements of this specification and those tests cited in section 4.5.2.
3.10 Salt fog. The nets shall be capable of storage and operation in high temperature, high
humidity, salt laden, sea coast environments without damage or deterioration of performance.
3.11 Vibration. The nets shall be capable of withstanding vibration observed inside cargo
carrying aircraft.
3.12 Special marking. The nets shall be marked with 1-inch block letters to indicate outside, top
or side as applicable in accordance with the net type required and the 463L (see 6.4.2). Nets
shall be stenciled with ink in accordance with A-A-59291. The colors shall be in accordance
with FED-STD-595 as shown in TABLE III.
TABLE III. Marking colors.
NET TYPE
COLOR
COLOR CHIP NUMBER
CLASSIFICATION
TYPE I
Yellow
13538, 23538 or 33538
TYPE II
Yellow
13538, 23538 or 33538
TYPE V
Yellow
13538, 23538 or 33538
5
