AN7516 REV 4
RING
METHOD OF RING ATTACHMENT AT THIS POINT IS
OPTIONAL BUT MUST PERMIT RING TO SWIVEL
THROUGH 360°
AN PART NO HERE
CLEARANCE CIRCLE
1/2
1-1/4 DIA (MIN)
MAX
CONCENTRIC WITH STUD
30°
30°
PLATE
3.00
3-1/2
MAX
2-1/2 DIA
MAX
11/32
1-1/4
MIN
0.210
0.204 DIA
STUD, SEE DETAIL A
6 HOLES
PLATE SHAPE OPTIONAL
EQUALLY SPACED
STUD MAY BE SECURED
BY PEENING, WELDING OR
1/16
5/8 DIA
OTHER SUITABLE MEANS.
45°
1/8
3/8 MIN 11/64
1/32 RAD
4.00 RAD
5/64
MIN
3/8 DIA
FIGURE 1. Aircraft floor tie down adapter (AN7516-1).
2
